Expertly engineered…

Using the latest in engineering solutions, our individually designed Zip Wires will add an exciting dimension to any treetop adventure and allow you can take a truly adrenaline fuelled ride.

Bespoke designed with excitement and safety in mind, we offer a number of launch and landing platforms to choose from and a range of disc seat or knotted rope options. These are coupled with heavy-duty Zip Line and an option of a trolley with brakes, which can only be moved when in use. All parts that we use are commercial standard approved.

The possibilities are endless, and the options are all there for you to explore

Looking to install your very own Zip Wire project?



Zip Wires are the perfect addition to any family or adventure experience. Build your own wish-list today and our team will prepare some great ideas for you.

Start Your Project Today

Zip Wire Kit

Specifications

Materials
Zip Trolley

Professional Zip trolley – breaking load: 15 kN, minimum working load: 6 kN

Features a new level of safety to zip lines with an elegant pivot locking mechanism. This system makes attaching participants to cable faster and easier. It also ensures that the pulley cannot detach from the line while it is loaded. Features efficient steel bearings for high-speed adventure and stainless steel sheaves for durability.

Commercial braked Zip Wire trolley

This Stainless Steel Zip Wire Trolley has been TUV tested to meet and exceed European Safety Standards.

The trolley has both an internal brake and integrated finger protection. The internal brake ensures that the trolley only moves when someone is sitting on the seat which is attached to the trolley via the multi angled double shackle.

Screw gate carabiner

Oval-shaped carabiner decreases the chances of cross loading the gate and distributes the load evenly making it ideal for use with Zip Wire Trolleys. Strong and versatile with an alloy steel body & screw-locking gate.

Zip Wire Seat

The Zip Wire Rubber Seat can be used for domestic or commercial applications and offers superior comfort due to the rubber seat section and chain protector.

3m Brake Spring

Our 3m Stainless Steel Spring Brake is the ultimate in Zip Wire braking systems. The 3m Spring Brake offers a much more gentle end to the ride which is ideal for younger children or for faster rides.

Guide to EN 1176 and EN 1177 - Playground Equipment Standard:

SOURCE: An essential Guide to EN 1176 and EN 1177 by Wicksteed Playscapes

Safety requirements
  • Stop at end should progresssively slow down the Zip Wire trolley.
  • Angle of swing at the end should be less than 45°.
  • The Zip Wire trolley should not be removable except with tools.
  • No access to internal mechanism.
  • Suspension mechanism holding the seat or rope should be flexible and exclude the risk of strangulation OR,
  • Be installed at least 2m above the ground at the middle of the cable when loaded.
  • Children should be able to get off the seat at any time.
  • A tail must be prodided under the seat for pulling the Zip Wire trolley back to the start, but should present no risk of entrapment or strangulation.
  • Maximum loaded speed for children is 7m per second.
Dimension and distance requirements
  • Minimum ground clearance at rest of 300mm [400mm for single-point swings and tyre swings].
  • BS 5696-1:1997 [Play Equipment Intended for Permanent Installation Outdoors] – superseded/withdrawn, replaced by BS EN 1176 recommends a maximum height of 635mm for both cradle and flat seats.
  • Distance between seat and swing frame – 20% of swing suspension length + 200mm.
  • Distance between seats – 20% of swing suspension length + 300mm.
  • Seperation of seat suspension lines at the suporting crossbar – width between seat fixings + 5% of swing suspension length.
Free Space
  • 2m from Zip Wire trolley to Zip Wire seat
  • 2m each side of the Zip Wire seat when stationary, through the full length of the Zip Run.

adventure

fun

fantasy

make-believe

Zip Wires built and created for play

Start My Project

The Zip Wire is wild, even for adults.

Zip Wire Design & Build - Kids, Children and Family Spaces

Woodbridge, Suffolk, UK

Your next steps with us...

You create your wish-List

Click ‘Start My Project‘ and create your instant online wish-list.

We create your design

Our team will arrange an initial design call or home visit to discuss your wishlist and project.

You get an online proposal & pricing

We’ll craft your unique experience and send you a full online proposal with detailed pricing and options.

We build and install your WOW factor

We’ll do the rest, including designing, building and installing your dream project anywhere in the world.
Start your own Zip Wire project today... Start Project
